Fast speed metal cutting machinery plasma torch cutter for carton steel

Description

Details:

Condition: New
Place of Origin: Shandong, China (Mainland)
Brand Name: Jiaxin
Model Number: JX-1325
Voltage: 380V
Rated Power: 8.5KW
Dimension(L*W*H): 3380*2190*1690mm
Weight: 1400 KG
Certification: CE
Warranty: 2 Years
After-sales Service Provided: Engineers available to service machinery overseas
Keywords: Metal cutting machinery plasma torch cutter for carton steel
Working area: 1300*2500mm
Supplier: Hua yuan or hyper therm supplier
Driving system: stepper motor
Cutting speed: 15m/min
Control system: Starfire+THC
Rail: Round rail
Table structure: Heavy duty frame
Software: Fastcam Software

Video:

Description:

1. Y axis adopts double motors with double drivers. XYZ axis round rail, moving smoothly, with high accuracy. (option: Square rail)
2. Light beam design, good rigidity, light weight and tiny moving inertia.
3. Excellent performance on cutting 3D illuminated letters for advertising and channel letters on metal surface board
4. Work together with other advertising machines, such as CNC router and so on, improving working efficiency
5. Small cutting gap, no residua high cutting speed, high accuracy and low cost advanced CNC control system, Auto Arc, arcing success rate over 99%
6. Adopt well known plasma power supply and domestic cutting torch.

Images:

Fast speed metal cutting machinery plasma torch cutter for carton steel
